X-LAB RS5 105 12sp Hydrostatic Blue
Regular price
$2,599.90
includes GST
Couldn't load pickup availability
All Bikes come with a Free 2 Month Service. Call before ordering Bikes online re delivery Instructions.
Need help choosing the right size?
| Model | RS5 |
| Frame | X-LAB X6 Aluminum Frame, UDH Compatible |
| Fork | X-LAB Carbon Fork, 100x12mm Thru-axle |
| Stem | Branta Alloy Integrated |
| Handlebar | |
| Seatpost | XDS Carbon Seatpost, Aero Shape |
| Rear Derailleur | Shimano 105 RD-R7100, 12-Speed |
| Front Derailleur | Shimano 105 FD-R7100 |
| Shifters | Shimano 105 ST-R7120 |
| Brakes | Shimano 105 BR-R7170 |
| Cassette | CS-R9012, 12-Speed, 11-34T |
| Crankset | Branta Aluminum Power Meter Crankset, 52-36T, 24mm Steel Spindle, w/Apply Find My Anti-Theft Technology |
| Bottom Bracket | BSA 24mm |
| Rotors | Branta PN28, F:160 R:160mm |
| Chain | Shimano CN-M7100 |
| Wheelset | Branta A35 SL, Aluminum Rims |
| Tires | Branta R332, 700x32C, 60TPI |
| Saddle | Branta R302, Steel Rails |
| Weight | 9.54KG (Size L) |
| Max. Tire Clearance | 700x38mm |
| Frame | Size | XS | S | M | L | XL |
| A | Head Tube Angle (deg) | 71 | 72 | 73 | 73 | 73 |
| B | Head Tube Length (mm) | 115 | 135 | 155 | 180 | 205 |
| C | Seat Tube Angle (deg) | 75 | 74 | 74 | 73 | 73 |
| D | Seat Tube Length (mm) | 440 | 480 | 510 | 540 | 560 |
| E | Chainstay Length (mm) | 420 | 420 | 420 | 420 | 420 |
| F | BB Drop (mm) | 75 | 75 | 75 | 75 | 75 |
| G | Reach (mm) | 371 | 375 | 381 | 387 | 394 |
| H | Stack (mm) | 530 | 553 | 575 | 599 | 623 |
| I | Top Tube Length (mm) | 515 | 530 | 548 | 568 | 585 |
| J | Fork Length (mm) | 386 | 386 | 386 | 386 | 386 |
| K | Fork Rake/Offset (mm) | 50 | 50 | 50 | 50 | 50 |
| L | Trail (mm) | 71 | 65 | 58 | 58 | 58 |
| M | Wheelbase (mm) | 999 | 1001 | 1004 | 1018 | 1033 |
| N | Front Center (mm) | 590 | 592 | 596 | 609 | 624 |
| O | Stand-over Height (mm) | 725 | 758 | 784 | 810 | 831 |
| Components | Size | XS | S | M | L | XL |
| Stem | 80 | 80 | 100 | 100 | 100 | |
| Handlebar | 380 | 380 | 400 | 400 | 420 | |
| Crankset | 165 | 165 | 170 | 170 | 172.5 | |
| Seat Post | 300 | 300 | 300 | 400 | 400 |
| Sizing | Size | XS | S | M | L | XL |
| Recommended Rider Height | 148–158 cm 4'10"-5'2" |
158–168 cm 5'2"-5'6" |
168–176 cm 5'6"-5'9" |
176–183 cm 5'9"-6'0" |
183–191 cm 6'0"-6'3" |
