X-LAB MT2 Lava Black
Regular price
$1,099.90
includes GST
Couldn't load pickup availability
All Bikes come with a Free 2 Month Service. Call before ordering Bikes online re delivery Instructions.
Need help choosing the right size?
| Model | MT2 | |||||
| Frame | XDS X6 Aluminum Frame | |||||
| Fork | Branta Magniseum Alloy Suspension Fork, Coil Spring, Rebound Adjustable, 110mm Travel for 27.5''/ 120mm Travel for 29'' | |||||
| Stem | Branta Aluminum Stem, 85mm Length, 0 Degree Rise | |||||
| Handlebar | Branta Aluminum Handlebar, 660mm Width, 7 Degree Backsweep | |||||
| Seatpost | Branta Aluminum 31.6mm Seatpost | |||||
| Rear Derailleur | Shimano Cues SL-U6000-10R, 11-Speed | |||||
| Front Derailleur | / | |||||
| Shifter | Shimano Cues RD-U6020, 11-Speed | |||||
| Brakes | Branta C5 Hydraulic Brakes, 2 Pistons Caliper | |||||
| Cassette | Sugek, 11-46T, 11-Speed | |||||
| Crankset | Branta Aluminum Crankset, 170mm Length, 34T, Narrow-wide teeth | |||||
| Bottom Bracket | BSA 24mm | |||||
| Rotors | Branta Steel Rotors, F: 180mm R: 160mm | |||||
| Chain | SUMC | |||||
| Wheelset | Branta Aluminum XC Wheelset | |||||
| Tires | CST SERRATUS 29x2.25, 30TPI | |||||
| Saddle | Branta R200, BED Metal Rails | |||||
| Weight | 12.38KG | |||||
| Frame | Size | XS | S | M | L | XL |
| 27.5''x350 | 29''x380 | 29''x430 | 29''x480 | 29''x530 | ||
| A | Head Tube Angle (deg) | 66.5 | 66.5 | 66.5 | 66.5 | 66.5 |
| B | Head Tube Length (mm) | 90 | 100 | 105 | 115 | 130 |
| C | Seat Tube Angle (deg) | 74 | 75.5 | 75.6 | 75.4 | 75.3 |
| D | Seat Tube Length (mm) | 350 | 380 | 430 | 480 | 530 |
| E | Chainstay Length (mm) | 433 | 435 | 435 | 435 | 435 |
| F | BB Drop (mm) | 45 | 60 | 60 | 60 | 60 |
| G | Reach (mm) | 385 | 415 | 440 | 465 | 495 |
| H | Stack (mm) | 557 | 620 | 624 | 637 | 647 |
| I | Top Tube Length (mm) | 545 | 575 | 600 | 630 | 665 |
| J | Fork Length(mm) | 485 | 530 | 530 | 530 | 530 |
| K | Fork Rake/Offset (mm) | 39 | 45 | 45 | 45 | 45 |
| L | Trail (mm) | 110 | 111 | 111 | 111 | 111 |
| M | Wheelbase (mm) | 1081 | 1138 | 1165 | 1194 | 1230 |
| N | Front Center (mm) | 652 | 710 | 737 | 766 | 802 |
| O | Stand-over Height (mm) | 697 | 732 | 727 | 773 | 803 |
