2026 HIKO PATROL
Couldn't load pickup availability
If you are ordering - Bikes - online, please call us to discuss delivery instructions before completing your purchase. Please be aware that bikes cannot be shipped directly to customers in their original packaging; however, we can arrange for them to be on-shipped once prepared. Additionally, please note that an assembly fee applies.
Need help choosing the right size?
The Patrol comes in two frame/wheel sizes; Small 16.5” frame with 26” wheels and Large 18” frame with 27.5” wheels.
Dual suspension with front Air Fork and Rear Rebound adjusted shocks allow for a smooth a comfortable ride over mountain bike trails, but still give a more upright riding position so the rider can enjoy the view.
- Battery: 48V 15Ah 720Wh SAMSUNG
- Motor: ANANDA M100 – 120Nm 48V
- Front Fork: Suntour X1 Air
- Rear Shock: DNM AO38 with Rebound adjust
- Display: Colour LCD with HIKOBIKE NAVIGATION APP
- Charger: 48V 3A
- Throttle (LH Thumb): Max 32km/hr
- Top Speed:45 km/hr
- Lights: Front, Rear (and rear stop light)
- Pedal Assist: Torque sensor
- Frame Size: S = 16.5” (420mm seat tube, TT (horizontal) 580mm
- Brakes: Hydraulic power cut-off
- Tyres: Kenda Off Road
- Tyre Size: 26 x2.35”
- Gear Shifter: Shimano Trigger
- Derailleur: Shimano Deore 10spd
- Cassette: 11-34T Shimano
- Crank Set: 44T, 170mm
- Mud Guard: Full Alloy
- Chain Guard: Alloy
- Stem: UNO, Adjustable 31.8mm
- Seat Post: UNO 31.6
- Saddle: SR Lookin Basic, Width: 187mm
- Handle Bar : UNO Sweepback 9 Deg, Rise 15mm
- Pedals: Wellgo Spike B087
- Racks: Alloy Rear Rack
- Grips: Ergo
- Bike Weight (without battery): 28.2kg (720Wh Battery 3.8kgs)
- Max Load Weight: 130kg
- Warranty: 5yrs frame, 2yrs battery and motor, 1yr other components
