E-MTB with the weight of an MTB, starting at 15.5kg! Take the best Cross-Country/Trail platform to date, the Lumen 900, top it off with 130mm of travel, add a completely silent and powerful electric assistance, yet keep its legendary lightweight DNA, and you are ready to ride any trail at Nino’s speed.
Please note that bike specifications are subject to change without prior notice
FrameCarbon HMXIntegrated Suspension TechnologyFlex Pivot / Adjustable head angleSyncros Cable Integration SystemTQ HPR50 / UDH Interface / 12x148mm with 55mm Chainline
TravelFront: 130mm / Rear: 130mm
ForkFOX 34 Float Performance Elite Air FIT43 modes with low Speed adj. / Kabolt 15x110mm axle44mm offset / tapered steerer / Reb. Adj. / Lockout130mm travel
Rear ShockFOX NUDE 6T EVOL TrunnionSCOTT custom w. travel / geo adj.3 modes: Lockout-Traction Control-DescendLow Speed Adj. / Custom large Air volume / Reb. Adj.Bearing Hardware / Travel 130-90-Lockout / T165X45mm
Remote SystemSCOTT TwinLoc 2 TechnologySuspension & Dropper Remote3 Suspension modes
Drive UnitTQ HPR50 Mid Motor drive 50Nm max Torque / EU: 25kmh / US: 20mph
BatteryTQ Internal 360Wh
DisplayTQ HPRBluetooth / ANT+ / Dedicated Smartphone app
ChargerTQ 100-240V-4A
Rear DerailleurSRAM GX Eagle AXS Transmission 12 SpeedWireless Electronic Shift System
ShiftersSRAM GX Eagle AXS Rocker Controller
CranksetFSA Carbon crankset / 175mm / 34T
Chainguidee*thirteen / e*spec Slider
ChainringScott custom spider / SRAM Eagle Transmission 34T chainring
ChainSRAM CN GX Eagle Transmission
CassetteSRAM GX Eagle XS 1275 Transmission 10-52
BrakesSRAM Level Silver Stealth 4-Piston Disc
RotorSRAM HS2 CL Rotors / F&R 180mm
HandlebarSyncros Fraser iC SL DC Carbon0° rise / back sweep 8° / mini Rise / 760mmSyncros Performance XC lock-on grips
SeatpostFOX Transfer Dropper Post31.6mm / S size 125mm / M size 140mmL size 150mm / XL size 175mm
SeatSyncros Tofino 1.5 RegularTitanium rails
HeadsetSyncros - Acros Angle adjust & Cable Routing HS SystemStainless+-0.6° head angle adjustmentZS56/28.6 – ZS56/40 MTB
WheelsetSyncros Silverton 1.5-30 CLF: 15x110mmR: 12x148mm30mm Tubeless ready rim 28H / XD DriverSyncros Axle w/Removable Leverwith 6mm AllenT30 and T25 Tools
Front TireSchwalbe Wicked Will 29x2.4" EVOSuper Race / TLE / 67EPI / Addix Speed Soft
Rear TireSchwalbe Wicked Will 29x2.4" EVOSuper Race / TLE / 67EPI / Addix Speed Grip
ExtrasSRAM AXS PowerpackSyncros Fork Fender
AccessoriesSyncros Eco SealantTransport Axle
Approx weight in KG16.6 (with tubes)
Approx weight in LBS36.6 (with tubes)
Max. System Weight128kgThe overall weight includes the bike, the rider, the equipment, and possible additional luggage.
